    ASTM A513-5 Dom Steel Tubing For Hydraulic Cylinder And Pneumatic Cylinder

    Ask Lasest Price
    Brand Name : Torich
    Model Number : GB/T3639、GB/T8713、EN10305-1:2002、EN10305-2:2002、 ASTM A519-2006、ASTM A513-2007、GB/T1591-2008、GB/T17396-2009
    Certification : GB/T 19001-2008 , ISO 9001:2008 , TS16949
    Price : USD1700-1800 per ton
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 6000MT
    Delivery Time : 30-45 days
    • Product Details
    • Company Profile

    ASTM A513-5 Dom Steel Tubing For Hydraulic Cylinder And Pneumatic Cylinder

    ASTM A513-5 DOM Steel Tube For Hydraulic Cylinder And Pneumatic Cylinder


    Standard : GB/T3639, GB/T8713, EN10305-1:2002, EN10305-2:2002,
    ASTM A519-2006, ASTM A513-2007, GB/T1591-2008, GB/T17396-2009

    Material: 20#, 45#, Q345B, Q345D, 25Mn, 27SiMn, E355


    Hydraulic and pneumatic cylnder tube standard/size/tolerance

    Working method


    Tube ID

    (mm)

    Length

    (m)


    Straightness
    (mm/m)

    Tolerance

    on ID

    Tolerance

    on WT


    ID Roughness

    (um)

    Cold Draw40-400≤12m0.2-0.5　/±5%≤1.6
    Cold Rolled40-150≤12m0.2-0.5　/±5%≤0.8
    Cold Draw-Honed40-400≤8m0.2-0.3H8-H9±5%≤0.4
    Cold Draw-Rolling50-300≤8m0.2-0.3H8-H9±5%≤0.4
    Deep hole boring-Roing250-400≤8m0.2-0.3H8-H9±8%≤0.8
    Deep hole boring-Honed Roing250-400≤8m0.2-0.3H8-H9±8%≤0.4

    Mechancial property
    　

    Final supply condition


    Steel grade

    		Cold finished(hard)(BK)(Cold drawn and stress-relieved(BK+S)

    T.S

    bN/mm2

    		Elogation 5%T.S bN/mm2Y.S Bn/mm2Elogation 5%Hardness HBImpact value(-20℃)J
    20≥550≥8≥520≥400≥15170/
    45≥680≥5≥630≥520≥12190/
    Q345B≥660≥8≥620≥520≥15190/
    Q345D≥660≥8≥620≥520≥15190≥27
    25Mn≥640≥8≥620≥510≥15190/
    27SiMn≥780≥5≥700≥580≥10210/
    E355≥700≥8≥650≥580≥15195≥27

    Chemecal composition
    　

    Steel grade    		CSiMnPSCrNiCuV
    200.17-0.230.17-0.370.35-0.65≤0.035≤0.035≤0.25≤0.30≤0.25/
    450.42-0.500.17-0.370.50-0.80≤0.035≤0.035≤0.25≤0.30≤0.25/
    Q345B≤0.20≤0.50≤0.17≤0.035≤0.035≤0.30≤0.50≤0.30≤0.15
    Q345D≤0.18≤0.50≤0.17≤0.030≤0.025≤0.30≤0.50≤0.30≤0.15
    25Mn0.24-0.321.10-1.401.10-1.40≤0.035≤0.035≤0.30≤0.30≤0.20/
    27SiMn0.22-0.290.17-0.370.70-1.0≤0.035≤0.035≤0.25≤0.30≤0.25/
    E355≤0.22≤0.50≤1.60≤0.035≤0.025////

    (Tolerance on ID) um
    　
    ID Size(Tolerance on ID)um
    H7H8H9H10
    30+21
    0    		+33
    0    		+52
    0    		+84
    0
    >30-50+25
    0    		+39
    0    		+62
    0    		+100
    0
    >50-80+30
    0    		+46
    0    		+74
    0    		+120
    0
    >80-120+35
    0    		+54
    0    		+87
    0    		+140
    0
    >120-180+40
    0    		+63
    0    		+100
    0    		+160
    0
    >180-250+46
    0    		+72
    0    		+115
    0    		+185
    0
    >250-315+52
    0    		+81
    0    		+140
    0    		+210
    0
    >315-400+57
    0    		+89
    0    		+170
    0    		+230
    0

    ASTM A513-5 Dom Steel Tubing For Hydraulic Cylinder And Pneumatic CylinderASTM A513-5 Dom Steel Tubing For Hydraulic Cylinder And Pneumatic CylinderASTM A513-5 Dom Steel Tubing For Hydraulic Cylinder And Pneumatic Cylinder
